HIEL CORPORATION
SMD 타입

 SMD 타입
SMD-TYPE Series

1) Applications & Merit

● Over Current/Temperature Protection
  - LED Dimmer, In battery pack, notebook etc.
● Possible to mount with high-density because of
  small size and light weight
● Not noisy


2) Construction & Dimensions

  1608 2012 3225
L 1.60±0.15 2.00±0.20 3.20±0.20
W 0.80±0.10 1.25±0.20 2.50±0.20
T 0.80±0.10 0.80±0.20 1.60±0.20
a 0.35±0.15 0.75+0.00
    -0.60		 0.75+0.00
    -0.60
b min. 0.35 min. 0.50 min. 1.00



3) Specifications
